Description
The Samsung LH55VHRRBGBXUE is a high-performance 55-inch video wall display designed for impactful and seamless visual experiences. With ultra-narrow bezels and vibrant, accurate colors, it is ideal for control rooms, retail displays, corporate environments, and digital signage applications.
Seamless video walls with razor-thin bezels
With an exceptionally narrow bezel measuring just 0.44 mm and equipped with Samsung’s advanced picture enhancement technology along with wide viewing angles, the VHR-R delivers an impactful and seamless experience. Its modern, slim design allows the display to blend into any business environment.
Nearly invisible 0.44 mm bezel
An Exceptionally thin 0.44mm even bezel — a 0.88 mm bezel-to-bezel depth — enables content to be delivered as one seamless image. Additionally, the display helps to eliminate any potential image distortion and provides a more immersive viewing experience.
View content from any angle
The display’s wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear and accurate information regardless of video wall layout or location.
Image enhancement technology
Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, color saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, so details are easier to see.
Modern, slim design
VHR-R displays feature an elevated design aesthetic with an ultra-slim depth of less than 70 mm. This allows the display to save space and create a clean, modern look for retail or other public spaces.
Vibrant images 24/7
Experience brilliant image presentation with an impressive 700 nit brightness allowing businesses to deliver clear information 24/7. The display’s non-glare panels provide better visibility regardless of ambient light, ensuring critical information is always visible.
Convenient mobile calibration
Samsung’s Color Expert Pro Mobile solution provides a quick and easy video wall calibration through a mobile camera. With the solution’s intuitive UI, even non-expert users can adjust up to 3×3 video wall’s white balance simultaneously without the need for additional equipment.
*Samsung Color Export Pro Mobile is only available on certain smartphone models.
Comprehensive calibration
Samsung’s multi-step factory calibration process tunes video walls to uniform brightness and color throughout multiple displays. In addition to rigorous factory calibration, users can also manage brightness and color uniformity with Samsung’s Color Expert Pro, a powerful free software program.
Advanced UHD presentation
Samsung video walls provide an impressive UHD viewing experience with minimal effort. With daisy chain design utilizing DisplayPort 1.2 and HDMI ports, the VHR-R display can project UHD content across multiple screens up — to 5 x 5 — without requiring an external graphic card or UHD splitters.
Industry standard certified
The VHR-R series is EMC class B compliant, meeting strict standards of electromagnetic wave emission, while IP5x certification protects the display against dust and other conditions. The display packaging also passed a rigorous 4-step, ISTA-certified test to minimize possible damage during delivery.
*EMC: Electromagnetic compatibility*IP5x validation ensures satisfactory operation even with a certain level of dust inside the product. However, product operation is not guaranteed when exposed to particular types of dust, such as metal dust*ISTA: International Safe Transit Association
Intuitive all-in-one operations
The UHD Signage Player Box combines information processing and content management tools into a single platform, for added operational simplicity. Weighing just 0.6 kg, even with embedded MagicINFO S Player 6 and SSSP 6, the compact design of the box makes it an ideal solution.
* The Signage Player Box is sold separately.
Specifications
- Display55″
- Panel TypeDirect LED
- Pixel Pitch (HxV)0.63×0.63
- Resolution1,920 x 1,080
Specifications Detail
Display
- Diagonal Size 55″
- Panel Type Direct LED
- Resolution 1,920 x 1,080
- Pixel Pitch (HxV) 0.63×0.63
- Brightness (Typical) Max 700 cd/㎡
- Contrast Ratio 1,100:1
- Viewing Angle (H/V) 178/178
- Response Time 8ms
- Color Gamut 0.72 %
- Glass Haze 0.28 %
- H-Scanning Frequency 57.3kHz ~ 70kHz
- Maximum Pixel Frequency 78MHz
- V-Scanning Frequency 47Hz ~ 63Hz
- Contrast Ratio (Dynamic) 30,000:1
Connectivity
- HDMI In 2
- DP In 1
- DVI In 1
- Tuner In No
- USB 1
- Component In No
- Composite In No
- IR In Yes
- HDBaseT In No
- Audio In Yes
- Audio Out Stereo Mini Jack
- Video Out Yes
- Power Out No
- RS232 In Yes
- RS232 Out Stereo Mini Jack
- RJ45 In Yes
- RJ45 Out No
Power
- Power Supply AC 100 to 240 VAC (60 / 50Hz)
- Power Consumption (On Mode) 270W
- Power Consumption (Sleep Mode) 0.5W
Dimension
- Set Dimension (WxHxD) 1211.0 x 681.7 x 69.9 mm
- Package Dimension (WxHxD) 1414.0 x 844.0 x 257.0 mm
Weight
- Set Weight 16.8 kg
- Package Weight (kg) 25.1 kg
Operation Conditions
- Temperature 0℃~ 40℃
- Humidity 10 ~ 90%
Mechanical Specification
- VESA Mount 600 x 400 mm
- Bezel Width 0.44 (even)
- Frame Material Glossy
General Feature
- External Memory Slot No
Optional Feature
- Mount Yes
- Stand No
Internal Player (MagicInfo)
- MagicInfo Daisychain Videowall Support Yes
Eco
- Energy Efficiency Class B
Certification and Compliance
- EMC Class B
- Safety 60950-1
